SENSORS OF PRESSURE
DIFFERENTIAL PRESSURE TYPE DBP & DMP Zone de Texte: ELECTRICAL CHARACTERISTICS



réf 01xxx Sensors without electronics
réf 11xxx Sensors Feeding 12V
   Sortie 0-5 ou 0 –10 volts
réf 21xxx Sensors Feeding   24V
   Sortie 0-5 ou 0 –10 volts
réf 41xxx Sensors Feeding  19 à 32V
   Output  4-20 mA


PERFORMANCES

Linéarité + Hystérésis+ Répétabilité

réf 41x01 =0,1% Full-Scale
réf 41x02 =0,2% Full-Scale
réf 41x05 =0,5% Full-Scale


Pressure ports ½ GAS, ¼ GAS, 10P100, Ties down pneurop, join high pressure NOVA BURTON CORBLIN, etc.


Temperature, compensating  [°C ]


T1 Compensation                 20°C
T2 Compensation     0  à    +80°C
T3 Compensation     0  à  +150°C
T4 Compensation     0  à  +250°C
T5 Compensation –20  à    +80°C
T6 Compensation –55  à  +125°C

Stemming versions and PARTICULAR SPECIFICATIONS in YOURS AREA of activity especially adapted to mining activities, public works, navy, aicraft, food, motorized, nuclear and rail.

Series equipped with 3 technologies in choices according to uses (Thin Film, Strain Gauges, Piezoresistive or thin film sensor element).



LOW PRESSURE TYPE BP

  This series is especially developed for the measure of differential pressures gas / gas where liquid / liquid. These versions accept very well brought up pressures of line up to 500 bars, and are able of measuring of very weak differential pressure.This range is introduced under several volumes. It also exists in miniature version.














  The series of sensors BP was especially developed for the measure of very weak dynamic and static pressure (absolute or relating pressure).The 8 ranges of measurements 0-5 mB in 0-2000 mB, are offered to you in 3 classes of precision from 0,1 % to 0,5%.Technologies used for this series are type gauges cook up pelliculaire, piézo-résistive and broadcast silicon.An effort was notably made for the thermal and mechanical découplage which without it forbids any stable measure.They can accept in some of the cases of corrosive fluids.This series is supplemented as all our sensors by a range electronic interface allowing the simple working of signs



















VERY HIGH PRESSURE TYPE HP





   This series was developed with a view to security notably on linkings essentials on the measurements of high pressure.
The expanses of measurements can attain 8000 bars. The ranges of offered precision are in numbers of 3 (0,5 % - 0,1 %).
The basic model is supplemented by the insertion of electronics allowing to have any types of electronic interfaces.













  PRESSURE scale MAX 500 Bars TYPE MP




  The series of sensor MP was developed for all applications of measure of static pressure or dynamics of 0-5 bars in 0-500 bars.Three classes of precision are available. This series is equipped with 3 technologies in choices according to uses (sound slim coat, sound pelliculaire woof, sound silicon), their structures were studied to acquire a découplage thermal and mechanical very strong.Mechanical linking is offered in a very big diversity (ex :10 p 100, ½ ou ¼ gaz).As a supplement, each of the basic models can accept the 4 electrical interfaces in order to be connected on all types of working of signs.Four versions diverted from this series are especially adapted to public works, marine, nuclear and rail
